. WebLogic Adapter for Manugistics ™ User Guide Release 7.0.3 Document Date: April 2003.

Restricted Rights Legend This software and documentation is subject to and made available only pursuant to the terms of the BEA Systems License Agreement and may be used or copied only in accordance with the terms of that agreement. It is against the law to copy the software except as specifically allowed in the agreement. Introduction. 1-1 How the BEA WebLogic Adapter for Manugistics Works. 1-3 How Services in the BEA WebLogic Adapter for Manugistics Work.1-3 How Events in the BEA WebLogic Adapter for Manugistics Work.1-5 How the Adapter Interfaces with Manugistics Processes.1-7 2. Tracing and Performance. 5-3 Creating Traces for Services and Events.5-3 Creating Traces for a Service.5-4 Creating or Modifying the Tracing Level for an Event.5-6 Creating Adapter Logs for an Event.5-9 BEA WebLogic Adapter for Manugistics User Guide.

About This Document The BEA WebLogic Adapter for Manugistics User Guide is organized as follows: Chapter 1, “Introducing the BEA WebLogic Adapter for Manugistics,”describes the components of the BEA WebLogic Adapter for Manugistics, describes its features, and presents a high-level description of how the adapter works. BEA WebLogic Adapter for Manugistics Installation and Configuration Guide BEA WebLogic Adapter for Manugistics Release Notes BEA WebLogic Server installation and user documentation, which is available at the following URL: BEA WebLogic Integration installation and user documentation, which is available at the following URL:. #include void main ( ) the pointer psz chmod u+w. tux data ap.doc tux.doc BITMAP float Identifies significant words in code. Monospace boldface Example: text void commit ( ) Identifies variables in code. Monospace italic Example: text String expr BEA WebLogic Adapter for Manugistics User Guide. Example: buildobjclient -v -o name -f file-list.l file-list.

Indicates the omission of items from a code example or from a syntax line. The vertical ellipsis itself should never be typed. Viii BEA WebLogic Adapter for Manugistics User Guide. HAPTER Introducing the BEA WebLogic Adapter for Manugistics This section introduces the components of the BEA WebLogic Adapter for Manugistics, describes its features, and presents a high-level description of how the adapter works. It includes the following topics: Introduction How the BEA WebLogic Adapter for Manugistics Works. BEA WebLogic Integration, true integration of Manugistics with all your various disparate applications is not only possible, it is very easy. Whether you are moving information into or out of Manugistics, the BEA WebLogic Adapter for Manugistics provides a proven, easy to use, cost effective architecture that: Protects your organization’s investment in legacy systems.

How Services in the BEA WebLogic Adapter for Manugistics Work Services configured in the BEA WebLogic Adapter for Manugistics allow you to use data from order processing, enterprise resource planning (ERP), and enterprise-wide data warehouse systems to update the Manugistics UDM. Relevant data for Manugistics includes order and sales information, purchase orders, inventory balances, and forecasts usually available in the external systems.The adapter uses the.

Leader in Supply Chain and Retail Solutions. With this knowledge, we help more than 4,0. View and Download BEA WebLogic user manual online. WebLogic Adapter for Manugistics.

As data becomes available in applications such as Oracle, Siebel, or SAP, and is passed to the adapter within the BEA WebLogic Integration environment, it is parsed by the adapter to ensure its compatibility with the Manugistics UDM. Use the Manugistics VIEWpoint client, a graphical user interface for the Manugistics platform, to configure a batch mode import file to match the data passed from the adapter. How Events in the BEA WebLogic Adapter for Manugistics Work Events configured in the BEA WebLogic Adapter for Manugistics allow you to use forecast data generated by Manugistics to update order processing, enterprise resource planning (ERP), and enterprise-wide data warehouse systems. Relevant data for the Manugistics NetWORKS solutions includes order and sales information, purchase orders, inventory balances, and forecasts usually available in the external systems.

UDM is updated with the forecast data, the adapter converts the data into XML and passes it through WebLogic Integration so that it can be used to update systems such as SAP and Siebel. For more information on the how the adapter works with Manugistics, see “How the Adapter Interfaces with Manugistics Processes”. The Manuba batch process uses this information to carry out the export of data from the Manugistics database.

The BEA WebLogic Adapter for Manugistics receives data from systems such as SAP and transforms the data into XML. Once it is in XML, the adapter can convert it to the format that can be used by the Manugistics Manuba process to update the Manugistics UDM. Introducing the BEA WebLogic Adapter for Manugistics When you configure services, you must provide information about your Manugistics system, such as the location of the Manuba batch file, that will allow the adapter to invoke the Manuba process. BEA WebLogic Adapter for Manugistics User Guide. HAPTER Creating and Configuring Events An event adapter is the inbound interface from a Manugistics application to WebLogic Integration Studio. This section describes how to create, configure, and test an event adapter. It contains the following topics: Creating an Application View Folder.

Creating and Configuring Events Here, is the IP address or host name where the WebLogic appserver-host Integration Server is installed, and is the socket on which the server is port listening. The port, if not changed during installation, defaults to 7001. For more information, see Chapter 4, “Creating Schema Repositories.” To create an event adapter application view: 1.

Log on to the WebLogic Integration Application View Console at Here is the IP address or host name where the WebLogic. If the application view is deployed, you can access the window by first undeploying the application view. Type the name of the BEA WebLogic Adapter for Manugistics session base directory in the Session path field. This directory holds your Manugistics schema information and contains the. A service should be added for each event that is used by the application view. To add an event to, and deploy, an event adapter application view: 1.

Log on to the WebLogic Integration Application View Console at BEA WebLogic Adapter for Manugistics User Guide. Creating and Configuring Events 2. Select the folder in which this application view resides.

Select the application view. In the Administration window of the WebLogic Integration Application View Console, choose Add Event.

The Add Event window opens. Figure 2-6 Add Event Window - ManugisticsSQL 5.

For example, if Maximum Rows is set to 5, and 23 new rows are found to have been added when the database is polled, four events containing five rows and one event containing three rows are created. BEA WebLogic Adapter for Manugistics User Guide. If no value is specified, connection will use the Driver, URL, UserId and Password specified in the service. Select a schema from the drop-down list.

User Guide

Select trace settings as follows: BEA WebLogic Adapter for Manugistics User Guide. For more information about tracing, Chapter 5, “Using Tracing.” 8. The Application View Administration window opens.

Figure 2-7 Application View Administration Window BEA WebLogic Adapter for Manugistics User Guide. You must deploy an application view before you can test its services and events or use the application view in the WebLogic Server environment. Application view deployment places relevant metadata about its services and events into a run-time metadata repository. Deploying an Application View Figure 2-8 Application Administration Window 2. Click Continue. The Deploy Application View window opens.

BEA WebLogic Adapter for Manugistics User Guide 2-11. To validate that the application view was successfully deployed, proceed to the main Application View Console window and double-click the folder in which you created the application view. You should see the name of the new application view with a status of deployed. 2-12 BEA WebLogic Adapter for Manugistics User Guide. You can test configuration using the Application View Console. To confirm that a deployed event adapter application view is correctly configured and can receive events: 1. Log on to the WebLogic Integration Application View Console at 2.

Select the folder in which the application view resides and then select the application view. This provides a 30-second period during which you can access the Manugistics client program (or your favorite utility) to manually invoke a request from Manugistics to your event adapter. 2-14 BEA WebLogic Adapter for Manugistics User Guide. Testing Event Adapter Application Views Using WLI Studio You can test configuration using WebLogic Integration Studio. To confirm that a deployed event adapter application view is correctly configured and can receive events: 1. Log on to WebLogic Integration Studio. Creating and Configuring Events Figure 2-14 Selecting Create Template in WebLogic Integration Studio 2.

In the Organization pane, select an organization to create a new workflow template. Right-click Templates and select Create Template.

The Template Properties window opens. Figure 2-15 Template Properties Window 4. Testing Event Adapter Application Views Using WLI Studio Figure 2-16 Displaying the New Template in WebLogic Integration Studio 7. To select node properties, right-click the Start node. Figure 2-17 Selecting Node Properties in WebLogic Integration Studio 8. Select Properties from the pop-up menu.

Select the variable type XML from the drop-down list. Select the Input and Output options in the Parameter group. Right-click the template in the organization pane of WebLogic Integration Studio and select Save.

Right-click the event definition folder and select Properties. Ensure that Active is checked. You may now initiate events from your Enterprise Information System (EIS). For the BEA WebLogic Adapter for Manugistics, you can create events through Manugistics Manuba or the Manugistics Client (ViewPoint) test program.

Creating and Configuring Events The Workflow Variables window opens. Click View XML to see the entire contents of the workflow message (messages are also known as documents). Figure 2-22 Workflow Variables Window 2-20 BEA WebLogic Adapter for Manugistics User Guide. HAPTER Creating and Configuring Services The service adapter for Manugistics is WebLogic Integration’s interface to Manugistics. It enables your business processes to move information to your Manugistics application system. This section describes how to create, configure, and test a service adapter application view.

It includes the following topics. The Configure Connection Parameters window opens. Figure 3-2 Configure Connection Parameters Window a. Enter the name of the BEA WebLogic Adapter for Manugistics session base directory in the Session path field. This directory holds your Manugistics schema information and contains the. To configure a service adapter application view: 1.

Log on to the Application View Console at Here, is the IP address or host name where the WebLogic appserver-host Integration Server is installed, and is the socket on which the server is port listening. Creating and Configuring Services Figure 3-3 Administration Window 3. From the left navigation pane, select Add Service. The Add Service window opens. Figure 3-4 Add Service Window. Description Trace Generates a basic trace that displays the input XML (up to 300 bytes) before parsing, and shows the request being processed. For more information about tracing, see Chapter 5, “Using Tracing.” BEA WebLogic Adapter for Manugistics User Guide.

Creating and Configuring Services Table 3-2 Trace Options Parameter Description Verbose Trace Generates a trace that displays configuration parameters used by the adapter. For more information about tracing, see Chapter 5, “Using Tracing.” Document Trace Generates a trace that displays the input document after it was analyzed and the response document being returned. You must deploy an application view before you can test its services and events or use the application view in the WebLogic Server environment. Application view deployment places relevant metadata about its services and events into a run-time metadata repository. Update service parameters, connection pool parameters, log configuration, and security as required.

For more information, see “Defining an Application View” in Using Application Integration: 4. Click Deploy to save and deploy the service adapter. The Summary for Application View Manugistics Service window opens on.

You can test using the Application View Console. To confirm that a deployed service adapter application view is correctly configured: 1. Log on to the WebLogic Integration Application View Console at 2. Select the folder in which the application view resides and then select the application view.

Creating and Configuring Services Figure 3-9 Application View Summary 3. The console displays the test entry input box. Figure 3-10 Test Service Window 4. In the text box, enter a valid XML string that will act as the request data. Figure 3-11 Test Service Output Testing Service Adapter Application Views Using WLI Studio You can test service adapter application views using WebLogic Integration Studio. To confirm that a deployed service adapter application view is correctly configured and that it can process services: 1.

Creating and Configuring Services Figure 3-12 WebLogic Integration Studio 3. Right-click Templates and select Create Template. The Template Properties dialog box appears. Figure 3-13 Template Properties Dialog Box a. Enter a name for your workflow template.

Right-click the new template and select Create Template Definition. The template appears in WebLogic Integration Studio. Right-click the Task node and select Properties. Figure 3-15 Choosing Node Properties in WebLogic Integration Studio The Task Properties dialog box opens. Figure 3-16 Task Properties 7. Creating and Configuring Services The Add Action dialog box opens. Figure 3-17 Add Action 8.

Click AI Actions, and then Call Application View Service. The Call Service dialog box appears. Figure 3-18 Call Service Dialog Box 3-14.

Click Set in the Call Service dialog box to set the request document. As this is only a partial workflow, the request document containing the request must be set. BEA WebLogic Adapter for Manugistics User Guide 3-15. Ensure that Active is checked. You can now initiate the workflow from the BEA Worklist.

From the Start menu, select BEA WebLogic Platform 7.0, WebLogic Integration 7.0, and then Worklist. Log on to Worklist. Testing Service Adapter Application Views Using WLI Studio Figure 3-21 WebLogic Integration Worklist Window - Workflow Start a. Select the workflow that was just created from the workflow list. You receive a message indicating that your workflow started successfully.

User Manual Template

Creating and Configuring Services 3-18. Without this metadata, the Application Explorer can't generate these schemas for you. Because Manugistics doesn't expose any of the metadata the BEA Application Explorer uses to generate the XML schemas, you must create these schemas. After you have created the schema repository and schemas, you can configure services and events. You assign each application view to a schema repository; several application views can be assigned to the same repository. All BEA WebLogic adapters use a schema repository to store their schema information for use by the Application View Console. The schema repository is a directory containing: A manifest file that describes the event and service schemas.

The manifest has a connection section and a schema reference section, named. The connection section contains default values that are used when schemaref creating the application view. The schema reference name appears in the schema BEA WebLogic Adapter for Manugistics User Guide.

The repository manifest is an XML file with the root element manifest and two sub-elements: appears once and is optional for the BEA WebLogic Adapter for connection Manugistics. If you do not want to enter default values, then include only the XML tags with no values. Creating a Schema Schemas describe the rules of the XML documents that traverse WebLogic Integration. You can generate a schema manually or by using a schema-generating tool.

Note: If you manually create an XML schema, the namespace prefix in the manifest. BEA WebLogic Adapter for Manugistics User Guide. BEA WebLogic Adapter for Manugistics User Guide.

BEA WebLogic Adapter for Manugistics User Guide. BEA WebLogic Adapter for Manugistics User Guide.

Creating Schema Repositories 4-10 BEA WebLogic Adapter for Manugistics User Guide. This section describes tracing for services and events. It contains the following topics: Levels and Categories of Tracing Tracing and Performance Creating Traces for Services and Events BEA WebLogic Adapter for Manugistics User Guide.

Using Tracing Levels and Categories of Tracing Tracing is provided by both the BEA adapter framework and by the BEA WebLogic Adapter for Manugistics. The BEA WebLogic Integration framework provides five distinct levels of tracing: Table 5-1 Levels of Tracing. The default setting is off. Note: To obtain the appropriate trace, both the level and the category must be declared. In a debug situation, BEA Customer Support will request (minimally) a Basic and a Verbose trace. Tracing and Performance The additional trace capabilities provided by the adapter are not strictly hierarchic. The Deploy Application View window opens.

Navigate to the Log Configuration area and select the desired trace level. This pane enables you to select the trace level for the BEA WebLogic Integration framework. BEA WebLogic Adapter for Manugistics User Guide. Creating Traces for Services and Events Figure 5-2 Deploy Application View window For maximum tracing, select Log all Messages.

This is recommended to obtain optimum debugging information for BEA support personnel. Note: This causes all generated messages to be written to the log.

Using Tracing Creating or Modifying the Tracing Level for an Event To create or modify the WebLogic framework tracing level for an event: 1. Logon to the BEA WebLogic Server Console. In the left pane, select Web Applications. Select BEAMGISTICS10EventRouter.war. Creating Traces for Services and Events Figure 5-4 WebLogic Server Console: Configuration This pane enables you to select the trace level for the BEA WebLogic Integration framework.

For maximum tracing, enter DEBUG. This is recommended to obtain optimum debugging information for BEA support personnel. This change need only be made once. It is set for all events associated with a given adapter.

Return to the WebLogic Server Console. Select Applications from the WebLogic Server Console. Select the adapter whose EventRouter you have modified in the previous steps. Select the Deploy tab in the right pane. Click Add to continue to the next configuration pane.

Click Continue to move to the next configuration pane. The Deploy Application View window opens. Navigate to the Log Configuration area and select the desired trace level. BEA WebLogic Adapter for Manugistics User Guide. Using Tracing This pane enables you to select the trace level for the BEA WebLogic Integration framework.

Figure 5-7 Deploy Application View window For maximum tracing, select Log all Messages. This is recommended to obtain optimum debugging information for BEA support personnel.
